Refrigerated Counter Chiller 2 Doors & 4 Drawers ( 2230*700)
The Blueline GN4140TN is a drawer chiller, running at -2 to +8 °C — refrigerated drawers rather than doors, so a pan is pulled out to the cook at waist height instead of being reached for at the back of a cabinet. At 860 mm high it sits in a standard counter run. The cabinet measures 2230 × 700 × 860 mm. Inside, the usable chamber is 1663 × 580 × 589 mm.
Power is a single-phase 230 V / 50 Hz supply, so no three-phase provision is needed. At 173 kg empty it takes two people and a trolley to site. It runs on R290, a hydrocarbon refrigerant with a global warming potential of 3; the charge is sealed and small but flammable, so keep the ventilation clearance the installation sheet specifies. The compressor is an Embraco / ZEL unit under a Dixell digital thermostat, mainstream parts an engineer can source locally.
616 litre gross capacity at -2 to +8 °C. 2230 × 700 × 860 mm external footprint. Robust Stainless Steel Construction – Ensures durability, hygiene, and long-lasting performance. Ventilated Cooling System – Provides uniform temperature distribution for optimal food preservation. High-Density Insulation – Enhances energy efficiency and maintains consistent cooling.
